Khoom Description
Khoom nta
1. Kev Ua Tau Zoo:
Resistant rau cua thiab daus, corrosion, xeb thiab laus, haum rau hnyav sab nraum zoov ib puag ncig. Cov kab kev txhawb nqa siab tau xa cov cua zoo tshaj plaws thiab seismic tsis kam nrog tsawg deformation, ua kom muaj kev nyab xeeb siab, kev ntseeg siab thiab ruaj khov. Lub kaw ntom nti muab cov dej noo thiab tiv thaiv kab. Cov kev txawj ntse yooj yim tuaj yeem ua tiav los ntawm kev sib piv cov cuab yeej txhawb nqa.
2. Cov txiaj ntsig zoo:
Kev ntsuas kub ntsuas thiab qhov cua ua kom tsis txhob muaj kab mob mildew loj hlob thiab txo cov qoob loo. Kev ua haujlwm sib xyaw ua ke tuaj yeem ua tiav los ntawm kev sib txuas nrog ziab, xa khoom thiab lwm yam khoom siv. Lub conical hauv qab qhov chaw nres nkoj tuaj yeem txuas nrog elevators thiab conveyors, tsim ib lub tsev khaws khoom me me thaum ua ke nrog cov tshuab ziab khaub ncaws. Nws cushions thiab tiv thaiv cov ntaub ntawv thaum lub sijhawm ua haujlwm ruaj khov nrog kev ua haujlwm qis thiab kev saib xyuas cov nqi.
Khoom Specifications
| Qauv | Silo Top Angle | Hauv qab Cone Angle | Silo Diameter | Total Silo Height | Silo Plhaub Qhov siab | Silo Volume | Maximum Silo Capacity | Khoom siv |
| 100T | 25 degree | 45 degree | 4.5m | 12.53m | 7.91m | 150m³ | 110 tons | 275g Kub-Dip Galvanized Anti-Corrosion Steel Phaj |
| 300T | 25 degree | 45 degree | 6.417m | 17.33m | 11.27m | 418m³ | 310 ton | |
| 500T | 25 degree | 45 degree | 8.25m | 18.87m | 11.27m | 718m³ | 535t ua | |
| 1000T | 25 degree | 45 degree | 10.084m | 24.73m | 15.75m | 1468m³ | 1100 tons | |
| 1500T | 25 degree | 45 degree | 11.9m | 27.27m | 16.87m | 2231m³ | 1600 tons | |
| 2000T | 25 degree | / | 13.75m | 20.87m | 16.87m | 2701m³ | 2020 tons | |
| 3000T | 25 degree | / | 16.5m | 22.5m | 17.99m | 4186m³ | 3100 tons | |
| 5000T | 25 degree | / | 20.1m | 25.74m | 20.23m | 7082m³ | 5 300t | |
| 10000T | 25 degree | / | 27.5m | 29.98m | 22.47m | 14918m³ | 11100 tons | |
| 15000T | 25 degree | / | 32.085m | 31.23m | 22.47m | 20662m³ | 15400 tons | |
| Nco tseg: Lub peev xwm tau teev tseg yog xam raws li cov nplej ntau ntom ntawm 0.75 tons ib cubic meter. |
||||||||
Daim ntawv thov Scenario
Txoj Cai Ua Haujlwm ntawm Conical -Steel Silos hauv qab
1. Cov Khoom Siv Cia: Cov nplej yog xa los ntawm lub elevator rau hauv qhov chaw kaw ntawm lub silo rau kev khaws cia.
2. Grain Condition Monitoring: Kev ntsuas qhov ntsuas kub thiab qhov cua tshuab ntsuas qhov ntsuas kub thiab av noo hauv lub silo hauv lub sijhawm.
3. Qhov cua thiab cua txias: Lub tshuab cua cua qhia cov cua qhuav kom dissipate noo noo thiab inhibit grain cua sov thiab pwm loj hlob.
4. Tso tawm: Ua tsaug rau lub conical - hauv qab tsim, cov nplej ntws tawm ib txwm nyob rau hauv nws tus kheej qhov hnyav raws lub conical nto; qhov no ua kom huv si tsis muaj qhov xav tau ntawm phau ntawv ntxuav.
FAQ
Q: Peb yog leej twg?
A: Peb yog cov chaw tsim khoom nrog peb tus kheej lub rooj cob qhia thiab R & D pab pawg.
Q: Cov cuab yeej puas txhawb kev hloov kho?
A: OEM / ODM customization muaj nyob rau qhov ntev, qhov chaw tshav kub, tswj tshuab, muaj peev xwm ntau lawm thiab lwm yam.
Q: Vim li cas thiaj xaiv peb?
A: 1).Peb yog Cov Chaw Tsim Khoom ntawm Cov Khoom Siv Ua Khoom Noj. 2).100% QC tshuaj xyuas ua ntej xa khoom xa tuaj. 3).Peb cov khoom tau raug muag rau ntau lub tebchaws thiab cheeb tsam, suav nrog Europe, Amelikas, Southeast Asia, Africa, thiab lwm lub tebchaws, thiab tau txais lub koob npe zoo.
Q: Lub sijhawm khoom xa tuaj ntev npaum li cas?
A: Peak Lub Sijhawm Lead: 1-3 lub hlis Tawm Lub Sijhawm Lead: ib hlis
Q: Peb puas tuaj yeem tuaj xyuas lub Hoobkas?
A: Lub Hoobkas kuaj xyuas ntawm qhov chaw tau txais tos, thiab kev txais tos tuaj yeem teem caij nrog kev teem sijhawm ua ntej.
Henan Huinong Machinery Co., Ltd. yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm me me hopper hauv qab silo nyob rau hauv Suav teb. Nrog kev paub ntau ntxiv, peb zoo siab tos txais koj los yuav cov khoom siv hluav taws xob me me hauv qab ntawm tus nqi qis los ntawm peb lub hoobkas. Customized xaj yog txais tos.
Cim npe nrov: me me hopper hauv qab silo, Tuam Tshoj me me hopper hauv qab silo manufacturers, lwm tus neeg, Hoobkas
